Yamaha HS8I
Yamaha HS8I
Overview
The black HS8I 2-Way Bi-Amp Powered Studio Monitor from Yamaha features 120W of output power, a 8.0" cone woofer, a 1" dome tweeter, response-tailoring controls to match the speaker output to a wide range of acoustic spaces, and a standard XLR connector along with a phone jack for direct connection of electronic musical instruments and other sources. The powered studio monitor can be used to reproduce audio in various environments such as recording studios, home studios, cafes, restaurants, and more.
Built with a low-resonance enclosure design, the HS series MDF cabinet delivers a damped acoustic response that is well suited for reference monitors. The bi-amp design offers a 75W amp for the woofer, and a 45W amp for the tweeter. Other features include noise-reduction technology to reduce audible noise up to 6 dB at the speaker port. In addition, the HS8I studio monitor can be wall or ceiling mounted.
Key features
- For Mounting on Walls and Ceilings
- 8.0" Cone Woofer
- 1" Dome Tweeter
- Bi-Amp Design
- Low-Resonance MDF Enclosure
- Noise Reduction Technology
- XLR and TRS Inputs
- Flexible Mounting Options
Specifications
| Monitor Type | Active 2-Way |
| Enclosure | Bass-Reflex, Shielded |
| Power Rating | 120 W Peak |
| Drivers | HF Driver: 1 x 1" / 2.5 cm Dome Tweeter LF Driver: 1 x 8" / 20.3 cm Cone |
| Amplification | HF Amplifier: Rated at 45 W LF Amplifier: Rated at 75 W |
| Frequency Range | 47 Hz to 24 kHz (at -3 dB) 38 Hz to 30 kHz (at -10 dB) |
| Analog Input Sensitivity/Gain | -10 dBu (Continuously Variable) |
| EQ | 1 x HF Shelf: -2 to +2 dB 1 x LF Shelf: -4 to 0 dB at 500 Hz (2 dB Increments) |
| Crossover Frequency | 2 kHz |
| Audio I/O | 1 x XLR Balanced Analog Input (10 Kilohms) 1 x 1/4" TRS Balanced Analog Input (10 Kilohms) |
| Power Consumption | 60 W |
| Enclosure Material | MDF |
| Mounting Points | 2 x M8 (Side Panels, Top Panel, Bottom Panel) |
| Dimensions (W x H x D) | 9.8 x 15.4 x 13.1" / 25 x 39 x 33.4 cm |
| Weight | 23.6 lb / 10.7 kg |
| Package Weight | 30.35 lb |
| Box Dimensions (LxWxH) | 20.9 x 16.2 x 14.2" |
In the Box
- Yamaha HS8I 2-Way Bi-Amp Powered Studio Monitor (Black)
- Limited 1-Year Warranty
