M-Audio BX Sub

M-Audio BX Sub

Rp. 5.800.000,00
Rp. 5.800.000,00 Rp. 5.800.000,00
Sale Sold out
Overview

Designed for low-frequency sound reinforcement in studio mixing applications, the M-Audio BX Premium Active 10" Studio Subwoofer offers a frequency response down to 20 Hz (-3 dB). Using a 10" fiberglass/paper composite driver with an oversized magnet and high-temperature 2" voice coil powered by 240-watt Class AB all-discrete internal amplifier. The amplifier offers a variable crossover between 50 and 200 Hz for fine tuning the response to your monitors. Physically, the subwoofer cabinet is constructed from heavily braced 0.75" Medium Density Fiberboard (MDF) with 1" front and rear baffles.

Key features
  • 10" Long Excursion Composite LF Driver
  • Oversized Magnet
  • 240W Class A/B Amplifier
  • All-Discrete Transistor Design
  • Stereo XLR/TRS/RCA Inputs
  • Variable Frequency Internal Crossovers
  • Includes Subwoofer Bypass Footswitch
  • High-Density Bass Reflex Cabinet
  • Removable Grill and Detachable Feet
  • 180-Degree Phase Reverse Switch
Specifications
Type Bass-reflex active powered subwoofer
Woofer 10.0" (25.4 cm) composite (treated paper/fiberglass) cone with high-temperature voice coil and damped rubber surround
Frequency Response 20-200 Hz (-3dB)
Crossover Adjustment HP/LP linked filter sweepable from 50-200 Hz; 24 dB/octave 4th-order alignment
Input Sensitivity 80 mV pink noise input produces 100 dBA output SPL at one meter with vol
Gain -30 to +6 dB
Amplifier 240 W average power into 4 ohms, discrete transistor design
SNR 96 dB (A-weighted)
THD 0.019% (mono mode)
Inputs 2x balanced/unbalanced XLR
2x balanced/unbalanced 1/4" TRS
2x unbalanced RCA
Output 2x balanced/unbalanced XLR outputs for satellites
2x unbalanced/unbalanced TRS outputs for satellites
Controls Volume/gain control
Phase inverse switch
Variable crossover control
Subwoofer bypass footswitch jack
Input Impedance 20 kOhm unbalanced
Maximum Input Level +20 dBu
Protection Over temperature, turn-on/off transient, subsonic filter, external mains fuse, DC protection, over current protection Indicator: Power on (blue) or standby/bypass (red)
Power Requirements Dual-voltage (selectable by rear-panel switch) for either 100-120V/~50/60Hz or 220-240 V / ~50/60 Hz; powered via detachable grounded IEC cable
Cabinet Vinyl-laminated high-density internally braced 3/4" MDF cabinet with 1" front and back baffles
Dimensions (H x W x D) 15.50 x 13.00 x 17.25" (39.4 x 33.0 x 43.8 cm)
Weight 54.60 lb (24.75 kg)
Packaging Info
Package Weight 45.6 lb
Box Dimensions (LxWxH) 21 x 20 x 17"
