Focusrite Scarlett Octopre
Focusrite Scarlett Octopre
Overview
Expand your studio via ADAT with eight 2nd generation Scarlett mic preamps. The Scarlett OctoPre is the ideal 8-channel expansion for any Scarlett - or other digital interface with ADAT inputs. ADAT is a simple and easy way of increasing the number of simultaneous recording channels available in your studio. With eight channels of Focusrite's 2nd generation Scarlett preamps and precision A-D conversion at sample rates up to 192 kHz, Scarlett OctoPre is the ideal way of increasing the number of inputs in your studio. It also offers eight balanced line outputs, sourced directly from their respective mic preamps for use on stage in a live environment. Eight natural-sounding 2nd generation Scarlett mic/line inputs deliver high headroom, plenty of clean gain, low noise and minimal distortion - ideal for tracking drums as well guitars, keyboards, vocals and more. The front panel features two newly designed instrument inputs with extended headroom. ADAT outputs let you connect to any interface or digital system with ADAT optical inputs, and analog line outputs let you feed an analog console at the same time as recording with the digital outputs. Frequency Response - 20Hz - 20kHz +0.5/-1.5dB
Key features
- Eight natural-sounding 2nd generation Scarlett mic preamps and eight balanced line inputs and dual front-panel instrument inputs
- Focusrite precision A-D conversion up to sample rates of 192 kHz
- Pad on every channel for extra headroom - ideal for loud sources such as drums
- Eight balanced line outputs - ideal for live use; Simple ADAT connectivity via optical cables
- Includes Red 2 & Red 3 AAX, AU & VST Plug-in Suite, and Softube Time & Tone Bundle as a free download upon registration; 2-year limited warranty on manufacturing defects.Noise EIN:-127 dBu. Focusrite now offers a 3-Year Warranty on this and all other Focusrite products.
Specifications
- SUPPORTED SAMPLE RATES
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
- MICROPHONE INPUTS
- Frequency Response
- 20Hz - 20kHz +0.5/-1.5dB
- Dynamic Range
- 109 dB (A-Weighted)
- THD+N
- <0.001%
- Noise EIN
- -127 dBu
- Maximum input level (without pad)
- +8 dBu
- Maximum input level (with pad)
- +16 dBu
- Gain Range
- 50 dB
- Input Impedance
- 3 kΩ
- LINE INPUTS
- Frequency Response
- 20Hz - 20kHz +0.5/-1.5dB
- Dynamic Range
- 109 dB (A-Weighted)
- THD+N
- <0.002%
- Maximum input level
- +22 dBu
- Gain Range
- 50 dB
- Input Impedance
- 49 kΩ
- INSTRUMENT INPUTS
- Frequency Response
- 20Hz - 20kHz +0.5/-1.5dB
- Dynamic Range
- 108 dB (A-Weighted)
- THD+N
- <0.01%
- Maximum input level
- +13 dBu
- Gain Range
- 50 dB
- Input Impedance
- 1 MΩ
- LINE OUTPUTS
- Maximum Output Level (0 dBFS)
- +16dBu @ 0dBFS, or >21dBu where ADAT output is not used
- THD+N
- <0.001%
- Ouput Impedance
- 136 Ω (Balanced) - for units with serial number ≤ W860083007515
- 576 Ω (Balanced) - for units with serial number > W860083007515
